opening systems
kiaro easy
Designed for smaller doors, without compromise.
Compact Drop Down Door System an elegant opening system defined by minimalist shapes and distinctly smooth movement. Engineered for compact cabinetry where every millimetre counts.
ordering code:
KIARO EASY
Soft (screw fixing door bracket)
for H=200mm CCW=1200mm Wt=2.8-5kg
for H=250mm CCW=900-1200mm Wt=2.6-4.2kg
for H=300mm CCW=600-900mm Wt=2.1-3.5kg
for H=350mm CCW=600mm Wt=2.5kg
COMPONENTS
2 pcs- 49504000A— Kiaro Easy Soft drop down doors, white
2 pcs- 49502000AB— Kiaro Easy Cover f.adjustments, white
2 pcs- 49503510YA— Visible door bracket w/cover f. Kiaro Nk/white
2 pcs- 40130000YA— KIMANA Skin hinge cabinet side Nk
2 pcs- 40130010YA— KIMANA Skin hinge door side Nk
2 pcs- 40150400YA— KIMANA Skin cabinet side cover Nk
2 pcs- 40150200YA— KIMANA Skin door side cover Nk
4 pcs- 60103160ZN— Chipboard screw panhead ø3.5 x 20mm Nk
4 pcs- 60101390ZN— Chipboard screw countersunk ø3.5 x 16mm Nk
8 pcs- 60101400ZN— Chipboard screw countersunk ø3.5 x 18mm Nk
KIARO EASY
Strong (screw fixing door bracket)
for H=350mm CCW=900-1200mm Wt=4-7.5kg
for H=400mm CCW=900-1200mm Wt=3.5kgs-6.7kg
COMPONENTS
2 pcs- 49506000AB— Kiaro Easy Strong drop down doors, white
2 pcs- 49502000AB— Kiaro Easy Cover f.adjustments, white
2 pcs- 49503510YA— Visible door bracket w/cover f. Kiaro Nk/white
2 pcs- 40130000YA— KIMANA Skin hinge cabinet side Nk
2 pcs- 40130010YA— KIMANA Skin hinge door side Nk
2 pcs- 40150400YA— KIMANA Skin cabinet side cover Nk
2 pcs- 40150200YA— KIMANA Skin door side cover Nk
4 pcs- 60103160ZN— Chipboard screw panhead ø3.5 x 20mm Nk
4 pcs- 60101390ZN— Chipboard screw countersunk ø3.5 x 16mm Nk
8 pcs- 60101400ZN— Chipboard screw countersunk ø3.5 x 18mm Nk
KIARO EASY
Soft (embedded door bracket)
for H=200mm CCW=1200mm Wt=2.8-5kg
for H=250mm CCW=900-1200mm Wt=2.6-4.2kg
for H=300mm CCW=600-900mm Wt=2.1-3.5kg
for H=350mm CCW=600mm Wt=2.5kg
COMPONENTS
2 pcs- 49504000AB— Kiaro Easy Soft drop down doors, white
2 pcs- 49502000AB— Kiaro Easy Cover f.adjustments, white
2 pcs- 49503010YA—Concealed door bracket w/cover f.KIARO Nk/white
2 pcs- 40130000YA— KIMANA Skin hinge cabinet side Nk
2 pcs- 40130010YA— KIMANA Skin hinge door side Nk
2 pcs- 40150400YA— KIMANA Skin cabinet side cover Nk
2 pcs- 40150200YA— KIMANA Skin door side cover Nk
4 pcs- 60103160ZN— Chipboard screw panhead ø3.5 x 20mm Nk
4 pcs- 60101390ZN— Chipboard screw countersunk ø3.5 x 16mm Nk
8 pcs- 60101400ZN— Chipboard screw countersunk ø3.5 x 18mm Nk
KIARO EASY
Strong (embedded door bracket)
for H=350mm CCW=900-1200mm Wt=4-7.5kg
for H=400mm CCW=900-1200mm Wt=3.5kgs-6.7kg
COMPONENTS
2 pcs- 49506000AB— Kiaro Easy Strong drop down doors, white
2 pcs- 49502000AB— Kiaro Easy Cover f.adjustments, white
2 pcs- 49503010YA— Concealed door bracket w/cover f.KIARO Nk/white
2 pcs- 40130000YA— KIMANA Skin hinge cabinet side Nk
2 pcs- 40130010YA— KIMANA Skin hinge door side Nk
2 pcs- 40150400YA— KIMANA Skin cabinet side cover Nk
2 pcs- 40150200YA— KIMANA Skin door side cover Nk
4 pcs- 60103160ZN— Chipboard screw panhead ø3.5 x 20mm Nk
4 pcs- 60101390ZN— Chipboard screw countersunk ø3.5 x 16mm Nk
8 pcs- 60101400ZN— Chipboard screw countersunk ø3.5 x 18mm Nk
